HEIDENHAIN iTNC 530 357
10.2 Miscellaneous Functions for Program Run Control, Spindle and Coolant
10.2 Miscellaneous Functions for
Program Run Control, Spindle
and Coolant
Overview
M Effect Effective at block... Start End
M0 Stop program run
Spindle STOP
Coolant OFF
îš„
M1 Optional program STOP
Spindle STOP
Coolant OFF (not effective during
Test Run)
îš„
M2 STOP program run
Spindle STOP
Coolant OFF
Go to block 1
Clear the status display (depends on
MP7300)
îš„
M3 Spindle ON clockwise îš„
M4 Spindle ON counterclockwise îš„
M5 Spindle STOP îš„
M6 Tool change
Spindle STOP
Program run STOP (depends on
MP7440)
îš„
M8 Coolant ON îš„
M9 Coolant OFF îš„
M13 Spindle ON clockwise
Coolant ON
îš„
M14 Spindle ON counterclockwise
Coolant ON
îš„
M30 Same as M2 îš„
