HEIDENHAIN iTNC 530 391
11.3 Fixture Monitoring (Software Option)
Operating FixtureWizard
FixtureWizard is operated primarily with the mouse. You can change
the screen layout by pulling the separator lines so that the Parameters,
Help graphics and 3-D graphic are displayed in the size you prefer.
You can change the depiction of the 3-D graphic as follows:
îš„ Enlarge/reduce the model:
Turning the mouse wheel enlarges or reduces the model
îš„ Move the model:
Pressing the mouse wheel and moving the mouse at the same
time moves the model
îš„ Rotate the model:
Pressing the mouse key and moving the mouse at the same time
rotates the model
In addition, buttons are available that perform the following function
when clicked:
Function Button
Exit FixtureWizard
Open a fixture template (files with the extension
CFT)
Switch between wire-frame and solid-object
view
Switch between solid and transparent view
Show/hide the designations of the collision
bodies defined in the fixture
Show/hide the test points defined in the fixture
(no function in the ToolHolderWizard)
Show/hide the measurement points defined in
the fixture (no function in the ToolHolderWizard)
Restore the initial position of the 3-D view
