592 Test Run and Program Run

16.1 Graphics

Switch the frame overlay display for the workpiece blank on/off:

U Shift the soft-key row until the soft key for the rotating and

magnification/reduction appears

U Select functions for rotating and magnifying/reducing:

U Show the frame for the BLK FORM: Set the highlight

in the soft key to SHOW

U Hide the frame for the BLK FORM: Set the highlight in

the soft key to OMIT
