624 MOD Functions
17.5 Setting the Data Interfaces
Assignment
This function sets the destination for the transferred data.
Applications:
îš„ Transferring values with Q parameter function FN15
îš„ Transferring values with Q parameter function FN16
The TNC mode of operation determines whether the PRINT or PRINT
TEST function is used:
You can set PRINT and PRINT TEST as follows:
File names
TNC mode of operation Transfer function
Program Run, Single Block PRINT
Program Run, Full Sequence PRINT
Test Run PRINT TEST
Function Path
Output data via RS-232 RS232:\....
Output data via RS-422 RS422:\....
Save data to the TNC’s hard disk TNC:\....
Save data to a server connected
to the TNC
servername:\....
Save the data in the same
directory as the program with
FN15/FN16.
Vacant
Data Operating mode File name
Values with FN15 Program Run %FN15RUN.A
Values with FN15 Test Run %FN15SIM.A
