HEIDENHAIN iTNC 530 645

17.12 Selecting the Programming Language for $MDI

17.12 Selecting the Programming

Language for $MDI

Application

The Program input MOD function lets you decide whether to program

the $MDI file in HEIDENHAIN conversational dialog or in ISO format.

 To program the $MDI.H file in conversational dialog,

set the Program input function to HEIDENHAIN

 To program the $MDI.I file according to ISO,

set the Program input function to ISO
