668 Tables and Overviews
18.1 General User Parameters
Configure tool table
(To omit from the
table: enter 0); Column
number in the tool
table for
MP7266.0
Tool name – NAME: 0 to 42; column width: 16 characters
MP7266.1
Tool length – L: 0 to 42; column width: 11 characters
MP7266.2
Tool radius – R: 0 to 42; column width: 11 characters
MP7266.3
Tool radius 2 – R2: 0 to 42; column width: 11 characters
MP7266.4
Oversize length – DL: 0 to 42; column width: 8 characters
MP7266.5
Oversize radius – DR: 0 to 42; column width: 8 characters
MP7266.6
Oversize radius 2 – DR2: 0 to 42; column width: 8 characters
MP7266.7
Tool locked – TL: 0 to 42; column width: 2 characters
MP7266.8
Replacement tool – RT: 0 to 42; column width: 3 characters
MP7266.9
Maximum tool life – TIME1: 0 to 42; column width: 5 characters
MP7266.10
Maximum tool life for TOOL CALL – TIME2: 0 to 42; column width: 5 characters
MP7266.11
Current tool life – CUR. TIME: 0 to 42; column width: 8 characters
MP7266.12
Tool comment – DOC: 0 to 42; column width: 16 characters
MP7266.13
Number of teeth – CUT.: 0 to 42; column width: 4 characters
MP7266.14
Tolerance for wear detection in tool length – LTOL: 0 to 42; column width: 6 characters
MP7266.15
Tolerance for wear detection in tool radius – RTOL: 0 to 42; column width: 6 characters
MP7266.16
Cutting direction – DIRECT.: 0 to 42; column width: 7 characters
MP7266.17
PLC status – PLC: 0 to 42; column width: 9 characters
MP7266.18
Offset of the tool in the tool axis in addition to MP6530 – TT:L-OFFS: 0 to 42
column width: 11 characters
MP7266.19
Offset of the tool between stylus center and tool center – TT:R-OFFS: 0 to 42
column width: 11 characters
TNC displays, TNC editor
