68 First Steps with the iTNC 530
1.3 Programming the First Part
U Call the menu for special functions
U Display the functions for point machining
U Select the pattern definition
U Select point entry: Enter the coordinates of the 4
points and confirm each with the ENT key. After
entering the fourth point, save the block with the END
key
U Display the menu for defining the cycle call
U Run the drilling cycle on the define pattern:
U Confirm Feed rate F=? with the ENT key: Move at
rapid traverse (FMAX)
U Miscellaneous function M? Switch on the spindle and
coolant, e.g. M13. Confirm with the END key: The TNC
saves the entered positioning block
U Retract the tool: Press the orange axis key Z in order
to get clear in the tool axis, and enter the value for the
position to be approached, e.g. 250. Confirm with the
ENT key
U Confirm Radius comp.: RL/RR/no comp? by pressing
the ENT key: Do not activate the radius compensation
U Confirm Feed rate F=? with the ENT key: Move at
rapid traverse (FMAX)
U Miscellaneous function M? Enter M2 to end the
program and confirm with the END key: The TNC
saves the entered positioning block
