686 Tables and Overviews
18.3 Technical Information
Input format and unit of TNC functions
Positions, coordinates, circle radii, chamfer
lengths
–99 999.9999 to +99 999.9999
(5.4: places before and after the decimal point) [mm]
Circle radii –99 999.9999 to +99 999.9999 if values are entered directly, radii up to
210 m possible via Q parameter programming
(5.4: places before and after the decimal point) [mm]
Tool numbers 0 to 32 767.9 (5.1)
Tool names 16 characters, enclosed by quotation marks with TOOL CALL. Permitted
special characters: #, $, %, &, -
Delta values for tool compensation –99.9999 to +99.9999 (2.4) [mm]
Spindle speeds 0 to 99 999.999 (5.3) [rpm]
Feed rates 0 to 99 999.999 (5.3) [mm/min] or [mm/tooth] or [mm/rev]
Dwell time in Cycle 9 0 to 3600.000 (4.3) [s]
Thread pitch in various cycles –99.9999 to +99.9999 (2.4) [mm]
Angle of spindle orientation 0 to 360.0000 (3.4) [°]
Angle for polar coordinates, rotation, tilting
the working plane
–360.0000 to +360.0000 (3.4) [°]
Polar coordinate angle for helical
interpolation (CP)
–99 999.9999 to +99 999.9999 (5.4) [°]
Datum numbers in Cycle 7 0 to 2999 (4.0)
Scaling factor in Cycles 11 and 26 0.000 001 to 99.999 999 (2.6)
Miscellaneous functions M 0 to 999 (3.0)
Q parameter numbers 0 to 1999 (4.0)
Q parameter values –999 999 999 to +999 999 999 (9 digits, floating point)
Labels (LBL) for program jumps 0 to 999 (3.0)
Labels (LBL) for program jumps Any text string in quotes (“”)
Number of program section repeats REP 1 to 65 534 (5.0)
Error number with Q parameter function
FN14
0 to 1099 (4.0)
Spline parameter K –9.999 9999 to +9.999 9999 (1.7)
Exponent for spline parameter –255 to 255 (3.0)
Surface-normal vectors N and T with 3-D
compensation
–9.9999999 to +9.9999999 (1.7)
