HID HDP5000 User Manual

All rights reserved HID Global Corporation
HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
108
Adjusting the Image Position controls
Use the Image Position controls to position the image on a card (to be adjusted).
Step Procedure
1 Adjust the Image Position values by clicking on the Vertical and Horizontal
adjustment arrows.
• These values ensure that the Cards always remain in the same position
as they travel through the Printer (regardless of image orientation).
• The Card Illustration (shown in the Image Position box) will flip and rotate
according to the selection of Portrait, Landscape or Rotate 180 Degrees.
• The outline around the illustration will always remain in the same
Landscape orientation.

HID HDP5000 Specifications

General

Print Resolution	300 dpi
Interface	USB
Print Technology	Dye sublimation
Card Capacity	100-card input hopper
Connectivity	USB 2.0
Print Capability	Single-sided
Operating System Support	Windows 7, 8, 10
Card Sizes	CR80 (standard credit card size)
