HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
278
Selecting the Calibrate Film tab
The two buttons for the Calibrate Film tab are described below.
• Calibrate button: Sends calibrate film command to Printer. Follow the instruction on the
page for setting up the Printer.
• Help button: Launches help specific to this tab.
Step Procedure
1 Select the Calibrate Film tab.
a. Ensure that the Film Cartridge is installed.
b. Ensure the Printer’s Cover is closed.
c. Click on the Calibrate button. (Note: The Printer’s LCD will display
CALIBRATE PASSED.)
d. Click on the OK button on the LCD display to complete the procedure.

HID HDP5000 Specifications

General

Print Resolution	300 dpi
Interface	USB
Print Technology	Dye sublimation
Card Capacity	100-card input hopper
Connectivity	USB 2.0
Print Capability	Single-sided
Operating System Support	Windows 7, 8, 10
Card Sizes	CR80 (standard credit card size)
