HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
271
Conducting the Tape Adhesion Test
Step Procedure
5 If the tape test indicates inadequate adhesion, increase the heat setting by 5
degrees, print another card and try the tape test again.
• Once the temperature has been increased 4 times (20 degrees), reset
temperature to default and increase the Dwell Time by .5 second.
• Repeat this process until adequate adhesion is achieved.
• Ensure that the cards (in use) have a surface roughness (Ra) of 60 micro
inches or less.
This information should be available from the card manufacturer.

HID HDP5000 Specifications

General

Print Resolution	300 dpi
Interface	USB
Print Technology	Dye sublimation
Card Capacity	100-card input hopper
Connectivity	USB 2.0
Print Capability	Single-sided
Operating System Support	Windows 7, 8, 10
Card Sizes	CR80 (standard credit card size)
