HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
306
Cleaning the Magnetic Encoder
Step Procedure
1 Open the front cover and remove the Film Cartridge.
2 Remove the Magnetic Cover to access the Magnetic Head.
3 Remove the Magnetic Head. See Display A below.
3 Use an alcohol wipe from the cleaning kit to clean the Magnetic Head. See
Display B below.
4 Replace the Magnetic Head and Magnetic Cover.
Display A
Display B

HID HDP5000 Specifications

General

Print Resolution	300 dpi
Interface	USB
Print Technology	Dye sublimation
Card Capacity	100-card input hopper
Connectivity	USB 2.0
Print Capability	Single-sided
Operating System Support	Windows 7, 8, 10
Card Sizes	CR80 (standard credit card size)
