HID HDP5000 User Manual

All rights reserved HID Global Corporation
HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
307
Cleaning the Magnetic Encoder when installed in the
Flipper
Step Procedure
1 Open the top cover of the Flipper Module.
2 Remove the Alcohol saturated Cleaning Card from the wrap.
3 Tilt the Flipper Table so it is UP & Down. The Magnetic Head is located
underneath the flipper module.
4 Insert the cleaning card in to the flipper table slot.
5 Open the printer cover.
Use the Forward and Back buttons to move the card back and forth.
Turn the card around and perform the task again.
6 Let the Magnetic head dry thoroughly before plugging the printer back in.

HID HDP5000 Specifications

General

Print Resolution	300 dpi
Interface	USB
Print Technology	Dye sublimation
Card Capacity	100-card input hopper
Connectivity	USB 2.0
Print Capability	Single-sided
Operating System Support	Windows 7, 8, 10
Card Sizes	CR80 (standard credit card size)
