All rights reserved HID Global Corporation
HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
140
Using the Click and Drag capability
Click and drag the corners and the sides of an area to change size and location of area.
• The Horizontal, Vertical size and X, Y coordinates update accordingly.
Click and drag the area to change the location.
• The X, Y coordinates update accordingly.
Selecting “inches or mm” radio button
Select from the inches or mm radio button to change the measurement type. (Note: This is
similar to the choice on the Card tab.)
• The inches radio button displays the area size and the location in inches.
• The mm radio button displays the area size and the location in mm.
Using the Add and Delete buttons
Step Procedure
1 Use the Add button for these capabilities:
• Add an area default sized to .2 (.2 at location “0” with focus on the added
area).
• Add multiple areas in the same location with the same affect (as if there
were only one area). (Note: Intersecting/overlapping areas do not
cancel each other out; instead, they act as one area.)
2 Using the Delete button to delete the area with focus from the graphic.
To Next Page
