HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
69
Selecting the Card Size
Step Procedure
1 Select the appropriate card option:
• CR-80: This selection is the default form size for the HDP5000. This will
print a 2.125 X 3.374 image including a .04 over-bleed on each of the 4
sides making the overall form size 2.204 X 3.452 (56 X 87.7 mm).
• Custom: This selection is used to create a custom form size from 1.0 x
3.0 to 2.204 to 3.452 (25.4 X 76.2 mm to 56 X 87.7 mm).
The dimensions of the total print area for each card size will appear in the Print
Width and Print Length boxes.
• These print area dimensions are .04" (1mm) larger than the actual card
size. This is so the Printer can overprint images to ensure they will appear
Edge-to-Edge when transferred to the card.
• For this reason, when designing a card format, always set the card size or
page size within the card design program to the exact Print Length and
Width dimensions listed in the Printer Driver.)

HID HDP5000 Specifications

General

Print Resolution	300 dpi
Interface	USB
Print Technology	Dye sublimation
Card Capacity	100-card input hopper
Connectivity	USB 2.0
Print Capability	Single-sided
Operating System Support	Windows 7, 8, 10
Card Sizes	CR80 (standard credit card size)
