HID HDP5000 User Manual

All rights reserved HID Global Corporation
HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
114
Using the Encoding Mode dropdown list
Use the Encoding Mode option to specify which magnetic encoding standard to use.
Category Description
Installation The HDP Card Printer can be installed with one of two types of
factory-installed Magnetic Stripe Encoding Modules.
Magnetic Encoding
options (changing
and modifying)
Change the encoding mode and coercivity setting or modify the ISO
standards for tracks 1, 2 and 3, by correctly modifying these
Magnetic Encoding options.
ISO Encoding
selection (active and
inactive functions)
If you select ISO Encoding, you send down a formatted set of
characters. (Note: This selection activates the track tabs. However,
all functions on the Track tabs are inactive/gray and display ISO
defaults, which are the defaults listed for each track below. The
Shift Data Left check box remains unchecked and inactive.)

HID HDP5000 Specifications

General

Print Resolution	300 dpi
Interface	USB
Print Technology	Dye sublimation
Card Capacity	100-card input hopper
Connectivity	USB 2.0
Print Capability	Single-sided
Operating System Support	Windows 7, 8, 10
Card Sizes	CR80 (standard credit card size)
