All rights reserved HID Global Corporation
HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
288
Using the Mag Top of Form Option
Use this option only if the Printer has a built-in Magnetic Stripe Encoder.
• If so, use this option to shift the starting point of where the Printer will begin encoding the
magnetic track data on a card's Magnetic Stripe.
• When adjusting this value, keep in mind that a card and its Magnetic Stripe will always
remain in the same relative position as the card travels through the Printer.
The diagram (below) represents:
• How the magnetic data will move in relation to the fixed position of a card's Magnetic
Stripe as a “positive” or “negative” Magnetic Offset value is entered.
• For this diagram, assume that the card is transparent and the card's Magnetic stripe can
be seen through the top or front side of the card.
Step Procedure
1 Enter a negative value to move the start of the magnetic data more toward
the leading edge of the card or the card output side of the Printer.
OR
Enter a positive value to move the start of the magnetic data toward the
trailing edge of the card or the card input side of the Printer.
• Magnetic Data Direction: The arrows on these buttons indicate the
direction the magnetic data will move on the card's Magnetic Stripe.
• Maximum Adjustment Range: The maximum adjustment range is ±
99. As a rule, 20 equals about .030"/. 8mm.) (Note: Keep this in mind
when adjusting this option to avoid over-adjusting.)
Caution: If the negative value is set too high, the Printer may
start encoding before the card's Magnetic Stripe reaches the encoding
head.
