HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
122
Using the Character Size buttons
Use this option to customize the Character Data Size (Bits per Character) used to encode
the magnetic data on the currently selected track. (Note: This character size includes the
parity bit (if enabled).)
Step Procedure
1
• Select 4 Bits to change the bits per character to 4 BPC.
• Select 5 Bits to change the bits per character to 5 BPC. (Note: This is
the default for Tracks 2 and 3).
OR
• Select 7 Bits to change the bits per character to 7 BPC. (Note: This is
the default for Track 1).
OR
• Select 8 Bits to change the bits per character to 8 BPC.

HID HDP5000 Specifications

General

Print Resolution	300 dpi
Interface	USB
Print Technology	Dye sublimation
Card Capacity	100-card input hopper
Connectivity	USB 2.0
Print Capability	Single-sided
Operating System Support	Windows 7, 8, 10
Card Sizes	CR80 (standard credit card size)
