HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
240
Using the Help page
The Help page displays the Help information.
Step Procedure
1 Open this web page at the appropriate location by clicking on the Help book
icon at the top of each page. See previous page.
2 Review the web interface for the Ethernet-enabled Printer.
Additional Ethernet Procedures
Accessing the Ethernet Status LEDs
The Ethernet Status LEDs can be found on the back of Printers.
Reviewing the HDP5000 LED Table
LED Flash Rate Indicates
On The Network link is present.
Green LED
(Left)
Off The Network link is not present.
Off There is NO network traffic to this IP address.
Amber LED
(Right)
Blinking There is Network traffic to this IP address.
