All rights reserved HID Global Corporation
HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
145
Selecting the Print YMC under the K and Print K Only
options
Step Procedure
1 Use the Defined Area function.
a. Define another area by clicking on the Defined Area. (Note: Another .2
x .2 (5mm x 5mm) area will appear in the lower left-hand corner. This is
the location in which all newly defined areas will first appear. Up to 5
areas can be defined.)
b. Delete an area by selecting the area and clicking on the Delete button.
(Note: If all areas are deleted, the K Panel Resin options will
automatically be deselected.)
2 Select the Print YMC Under K option to print all black in the designated
Defined/Undefined areas with the Yellow (Y), Magenta (M) and Cyan (C)
Ribbon Panels directly beneath the resin black (K) Panel. (Note: Select this
option if printing resin black text or barcodes onto a colored background to
provide a more gradual transition between the two.)
OR
Select the Print K Only option to print all black in the designated
Defined/Undefined areas only with the resin black (K) Panel or to print resin
black onto a white background to maximize the sharpness of printed text and
barcodes.
To Next Page
