All rights reserved HID Global Corporation
HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
89
Using the Print Both Sides - Split 1 Set of Ribbon Panels
option
Use this option to provide the most economical means of printing a dual-sided card since a
single set of Ribbon Panels will be split to print both the front and backside of a card.
• This option becomes active when Print Both Sides is checked.
• The Default is active and unchecked except for YMCKK, which is checked.
Step Procedure
1 Select this option to automatically print full-color on the front of a card and
resin black on the back of a card (using YMCKK Print Ribbons).
• If using a YMCKK Ribbon, the front of the card is printed with the YMCK
Panels and the back is printed with the second K Panel.
(Note #1: This option is automatically enabled when a YMCKK Ribbon type
is selected.)
(Note #2: This option is not available if using a YMCKH Ribbon.)
To Next Page
