HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
238
Using the Print Path page
The purpose of the Print Path page is to allow the User to view or change the TCP port
numbers used to communicate to the printer.
• If these settings are left to the default entry of 0 then the default ports of 9100, 5400 and
5402 will be used for the RawSocket TCP Port, the CPS Data TCP Port and the CPS
Command TCP Port respectively.
• The CPS Command TCP Port is dependent on the setting of the CPS Data TCP Port
and always two units higher.
Step Procedure
1 Select the Print Path link.
2 View the active configuration of the printer in the Current Settings area on
this page.
3 New port numbers may be entered into the Stored Settings area in the
text boxes provided on this page.

HID HDP5000 Specifications

General

Print Resolution	300 dpi
Interface	USB
Print Technology	Dye sublimation
Card Capacity	100-card input hopper
Connectivity	USB 2.0
Print Capability	Single-sided
Operating System Support	Windows 7, 8, 10
Card Sizes	CR80 (standard credit card size)
