HID HDP5000 - Loading the Overlaminate

All rights reserved HID Global Corporation
HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
50
Loading the Overlaminate
(Note: This procedure only applies to the HDP5000-LC.)
The loading process for both the Thermal Transfer Overlaminate and the PolyGuard™
Overlaminate material is the same. Refer to the following steps to load either type of
overlaminate into the Printer.
Step Procedure
1 Remove the overlaminate from its packaging.
2 Load the Lamination Rolls into the Cartridges until they click.
3 Tighten the Lamination Rolls.
