HID HDP5000 User Manual

All rights reserved HID Global Corporation
HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
223
Selecting the Log Type
Step Procedure
1 Select the System Log link. See the next page.
2 Select the link for the log name you want to view or configure (the default
choices are log1 or log2).
3 Select the Print Job Started checkbox to generate the log entries for each
Print Job Started.
4 Select the Printer Error checkbox to generate the log entries for each Printer
Error.
5 Select the Submit button.
6 Login as a root User if you are so prompted. (Note: Any change of setting
will only be accepted after you have successfully logged in.)

HID HDP5000 Specifications

General

Print Resolution	300 dpi
Interface	USB
Print Technology	Dye sublimation
Card Capacity	100-card input hopper
Connectivity	USB 2.0
Print Capability	Single-sided
Operating System Support	Windows 7, 8, 10
Card Sizes	CR80 (standard credit card size)
