HID HDP5000 User Manual

All rights reserved HID Global Corporation
HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
111
Adjusting the Transfer Dwell Time and Temperature
Step Procedure
3 Return to the factory default settings for the selected Card Type by clicking
on the Default button. If using cards (that differ from the Card Type Glossy-
PVC or Matte-PVC options), select one of the Card Type Custom options.
4 Adjust the dwell time and temperature settings to ensure proper image
transfer. Determine the appropriate settings for the card stock by setting the
Transfer Dwell Time and Transfer Temperature to the default settings.
Print a card.
a. If the HDP Film is not transferring properly, adjust these settings
accordingly.
OR
b. If the Film is transferring properly, perform a final durability test called the
Tape Test.
For instructions on how to do a tape test, see Conducting the Tape adhesion
Test procedure.

HID HDP5000 Specifications

General

Print Resolution	300 dpi
Interface	USB
Print Technology	Dye sublimation
Card Capacity	100-card input hopper
Connectivity	USB 2.0
Print Capability	Single-sided
Operating System Support	Windows 7, 8, 10
Card Sizes	CR80 (standard credit card size)
