HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
117
Using the Encoding Mode dropdown list
Category Description
Raw Binary
Encoding selection
(active and inactive
functions)
If you select Raw Binary Encoding, you send down a raw binary
string rather than a formatted set of characters. (Note: The
Coercivity dropdown function is active and the Bit Density,
Character Size, Reverse Bit Order and Add Leading Zeros are also
active and configurable for each track when Raw Binary Encoding
is selected).
Reverse Bit Order is used to reverse the character bits and is used
for the encryption of data in specific programs
Add Leading Zeros is used to add a set number of leading zeros
to the magnetic string in order to move the starting point of the
encoded data in specific programs for encryption of data.
Raw Magnetic Encoding
The User can select Raw Magnetic Encoding from the Driver.
Raw Coercivity
The User can select options for either High or Low Coercivity from
the Driver.
Raw Bit Density
The User can select the Configurable Bit Density option. This
option supports these standard configurable bit densities:
• 75 Bits Per Inch (BPI)
• 128 BPI
• 210 BPI
• Custom BPI
Raw Bit Density Per Track
The User can select the Configurable Bit Density, Character Size,
Reverse Bit Order and Add Leading Zero options for each individual
magnetic encoding track.

HID HDP5000 Specifications

General

Print Resolution	300 dpi
Interface	USB
Print Technology	Dye sublimation
Card Capacity	100-card input hopper
Connectivity	USB 2.0
Print Capability	Single-sided
Operating System Support	Windows 7, 8, 10
Card Sizes	CR80 (standard credit card size)
