HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
23
Technical Specifications
Term Description
Card Size (inches
and mm)
Choice of inches or mm changes the counter choice on the K Panel
Resin tab. See below.
• Inches displays card size in inches.
• mm displays card size in mm.
Changing Print Width or Print Length dimensions automatically
changes drop down to Custom.
Colors (dpi) 300 dpi (11.8 dots/mm)
Dimensions
• HDP5000: 11.50"H x 12.25"W x 9.25"D / 292mmH x 313mmW x
235mmD
• HDP5000 + Dual-Sided Module: 11.50"H x 17.50"W x 9.25"D /
292mmH x 445mmW x 235mmD
• HDP5000 + Single-Sided Lam Module: 12.75"H x 25"W x
9.25"D / 324mmH x 635mmW x 235mmD
• HDP5000 + Dual-Sided Module + Dual-Sided Lam Module:
12.75"H x 30"W x 9.25"D / 324mmH x 762mmW x 235mmD
• Lam Module: 12.75"H x 12.25"W x 9.25"D / 324mmH x
313mmW x 235mmD
Display User-friendly, SmartScreen™ LCD Control Panel

HID HDP5000 Specifications

General

Print Resolution	300 dpi
Interface	USB
Print Technology	Dye sublimation
Card Capacity	100-card input hopper
Connectivity	USB 2.0
Print Capability	Single-sided
Operating System Support	Windows 7, 8, 10
Card Sizes	CR80 (standard credit card size)
