HDP5000 High Definition Card Printer/Encoder User Guide L000950 Rev 1.8
265
Installing the Lamination Module Accessory
Step Procedure
6 Slide the Lamination Module attachment tabs and the PCB-INTF Board into
the appropriate slots at the base of Printer or Flipper Module.
7 Use the two (2) screws provided to attach the Lamination Module to the
Printer.
See Display A on the next page.
Display A - Shows the Printer, the Flipper Module and the Lamination Module. Slide the
Lamination Module attachment tabs and the PCB-INTF Board into the appropriate slots at
the base of Printer or Flipper Module.
