4.14 Mattress Assembly
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 38 Affinity® Three Birthing Bed and Affinity® Four Birthing Bed
Service Manual (MAN272 REV 4)
4.14 Mattress Assembly
Tools required: None
Removal
1. Set the brake/steer pedal to the brake position.
2. Ensure that the bed is out of the Trend-Like position.
3. Carefully lift the mattress from the head end of the bed.
CAUTION:
Do not pull on the mattress material when unfastening the mattress
retaining snaps. Unfasten the mattress retaining snaps at the snap
location. Failure to do so could result in equipment damage.
4. Locate and unfasten the two mattress retaining snaps beneath the seat
section.
5. If the mattress has air bladders, disconnect the two hoses located beneath
the seat section.
6. Lift the side panels on the foot section and unfasten the four snaps on the
foot mattress.
Replacement
1. To install the replacement mattress, reverse the removal procedure.
2. Ensure that the two air hoses are properly installed below the seat section.
3. Do the “Function Checks” on page 2-4.
