4.34 Central Braking System—P3700B Model—New Brake Style
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 86 Affinity® Three Birthing Bed and Affinity® Four Birthing Bed
Service Manual (MAN272 REV 4)
4.34 Central Braking System—P3700B Model—New Brake Style
Tools required: Phillips head screwdriver 1/8" drift punch
7/16" wrench Blue Loctite®
1
#242
Hammer ½" wrench
E-ring removal tool Anti-seize compound
Needle nose pliers Marker pen
(2) pieces of 2" x 4" x 36" lumber
Small screwdriver T25 Torx®
2
screwdriver
Red Loctite® #262
The brake/steer caster is located at the left-hand foot end of the base frame. The other three
casters are brake casters. To service the central braking system mechanism, lay the bed on its
side. Before you do this, you must disable the siderail and remove the brake/steer pedal.
Removal
1. Determine on which side the bed is to be placed.
2. Disable the siderail: lower it beneath the bed and tie it in this position, or
remove it as an assembly from the bed (refer to procedure 4.27).
3. Place the brake/steer pedal (A) into the steer position (see figure 4-43 on
page 4-87).
4. Remove the two screws (B) that attach the leg covers (C) to the bed (D).
5. Remove the leg covers (C).
6. Remove the foot-end rocker arm (E) as follows:
a. Remove the E-ring (F) from one side of the groove pin (G) that holds
the rocker arm (E) above the caster.
b. Remove the groove pin (G) to free the rocker arm (E).
c. Remove the spacers (H) on each side of the rocker arm (E).
d. Remove the hairpin (I) and connector pin (J) that attaches the metal
brake strip (K) to the rocker arm (E).
e. Lift out and remove the rocker arm (E).
1. Loctite® is a registered trademark of Loctite Corporation.
2. Torx® is a registered trademark of Acument Intellectual Properties, LLC.
