7.2 Oxygen Tank Holder (P276)
Chapter 7: Accessories
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 7 - 5
Service Manual (MAN272 REV 4)
7
7.2 Oxygen Tank Holder (P276)
Tools required: None
The oxygen tank holder attaches to the head end of the frame in a vertical
position. The oxygen tank holder accommodates one E-size oxygen tank with a
regulator. The mounting points are located to allow the attached oxygen tank
holders to pivot.
Installation
1. Install the mounting bar vertically into a mounting socket at the head end
of the frame.
2. Place one E-size oxygen tank in the holder.
3. Tighten the holder thumbscrew.
NOTE:
The thumbscrew keeps the oxygen tank from rotating in the holder.
Removal
1. Loosen the thumbscrew that holds the tank securely in the holder.
2. Lift the tank out of the holder.
3. Lift up on the tank holder, and remove it from the mounting sockets.
