7.1 Labor Bar (P3613)
Chapter 7: Accessories
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 7 - 3
Service Manual (MAN272 REV 4)
7
7.1 Labor Bar (P3613)
Tools required: None
Installation
The labor bar is intended to be used in the prescribed manner only.
Failure to use this product as outlined may result in personal injury or
equipment damage.
1. Determine the orientation of the labor bar that is required for the position
of the patient.
2. Insert the labor bar (A) into the leg support sockets (B) between the seat
and foot cushions (see figure 7-1 on page 7-3).
Figure 7-1. Labor Bar
