Hill-Rom Affinity Three - Caster Assembly-New Brake Style

4.35 Caster Assembly—New Brake Style
Chapter 4: Removal, Replacement, and Adjustment Procedures
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 4 - 89
Service Manual (MAN272 REV 4)
4
4.35 Caster Assembly—New Brake Style
Tools required: T25 Torx®
1
head bit 5/32" Allen™
2
wrench
Ratchet 3/16" Allen™ wrench
Bed jack Turpentine
P3700B—The foot-left caster is a brake/steer caster and the remaining casters
are brake casters.
Placing the brake/steer pedal in steer locks the left-hand foot end caster into a
position that is parallel to the bed (as described in chapter 1).
Removal
1. Set the brake/steer pedal to the brake position.
2. Remove the two screws (A) that hold the leg cover (B) over the caster (C)
(see figure 4-44 on page 4-90).
3. Remove the leg cover (B).
4. Remove the caster mounting screw (E).
5. Put a jack under the base frame, and raise the base frame high enough to
remove the caster (C).
WARNING:
Make sure the bed is stable before you remove the caster. Failure to do
so could cause personal injury or equipment damage.
6. Remove the caster (C) from the bed.
1. Torx® is a registered trademark of Acument Intellectual Properties, LLC.
2. Allen™ is a trademark of Industrial Fasteners, Inc.
