Recommended Spare Parts
Chapter 5: Parts List
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 5 - 7
Service Manual (MAN272 REV 4)
5
Recommended Spare Parts
For a recommended spare parts list to service five or more units, see
table 5-1 on page 5-7.
Table 5-1. Recommended Spare Parts
Part Number Quantity Description
450846048 2 Caster, 6" swivel
450848048 2 Caster, 8" swivel (Affinity® Three
Bed)
45084-6648 1 Caster, 6" brake
450848648 1 Caster, 8" brake
450846448 1 Caster, 6" brake/steer
4508468 1 Caster, 6" brake/steer (D model beds)
450848448 1 Caster, 8" brake/steer
63920 2 Hilow/Foot drive
63927 1 Head drive
4314317 5 Fuse, timelag, 4A, 125V AC,
5mmx20mm
4360519 5 Fuse, timelag, 2A, 250V AC,
5mmx20mm
65345 1 PCB assembly, control
67208 1 Interface board assembly
63945 1 Cable assembly, battery
6394201 1 Cable assembly, battery-to-battery
6642910S 5 Fuse, 10A, 32V DC, automotive style
150751 4 Plug
151085 1 Plug insertion tool
