4.28 Patient Siderail (Inboard) P.C. Switch Board
Chapter 4: Removal, Replacement, and Adjustment Procedures
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 4 - 69
Service Manual (MAN272 REV 4)
4
4.28 Patient Siderail (Inboard) P.C. Switch Board
Tools required: T25 Torx®
1
head bit Ratchet
T10 Torx® head bit
WARNING:
Adhere to all electrical safety precautions when servicing the bed’s
electrical system. Failure to do so could result in personal injury or
equipment damage.
Removal
1. Set the brake/steer pedal to the brake position.
2. Ensure that the bed is out of the Trend-Like position.
3. Using the head function, raise the head section to the high position.
4. Using the hilow function, raise the bed to the high position.
SHOCK HAZARD:
Unplug the unit from its power source. Failure to do so could result in
personal injury or equipment damage.
5. Unplug the bed from its power source, and engage the lockout control.
6. Using the ratchet and T25 Torx® head bit, remove the eight plastic screws
(A) that secure the patient siderail cover (B) to the siderail assembly (C)
(see figure 4-37 on page 4-70).
7. Carefully remove the patient siderail cover (B) from the siderail
assembly (C).
8. Note the orientation of the wires and cable assemblies to ensure proper
installation during the replacement procedure.
1. Torx® is a registered trademark of Textron, Inc.
