Hill-Rom Affinity Three - Function Checks

Function Checks
Chapter 2: Troubleshooting Procedures
Page 2 - 4 Affinity® Three Birthing Bed and Affinity® Four Birthing Bed
Service Manual (MAN272 REV 4)
Table 2-1. Quick Reference Problem/Solution Matrix
Function Checks
Function checks determine whether the bed is operating properly. All caregiver
control panel functions are available from both the right and left siderails.
When checking redundant function controls, activate each of the siderails to
determine if the fault is contained in one or both of the siderails.
1. Initial Actions have been performed.
Yes No
Go to “Initial Actions” on page 2-3.
2. The bed is plugged into an appropriate power source.
Yes No
Plug the bed into an appropriate power source.
Problem Solution
Hilow Drive Operation Failures RAP 2.1
Hilow Up Malfunction RAP 2.2
Hilow Down Malfunction RAP 2.3
Head Drive Operation Failures RAP 2.4
Head Up Malfunction RAP 2.5
Head Down Malfunction RAP 2.6
Foot Drive Operation Failures RAP 2.7
Foot Up Malfunction RAP 2.8
Foot Down Malfunction RAP 2.9
Hilow Up Malfunction (When The Foot Section Is Lowered) RAP 2.10
Brake Caster Malfunction RAP 2.11
Bed Air Surface Malfunction RAP 2.12
Night Light Does Not Illuminate RAP 2.13
Siderail Mechanism Does Not Hold RAP 2.14
Trend-Like Position Malfunction RAP 2.15
Battery Backup Malfunction RAP 2.16
CPR Release Malfunction RAP 2.17
