4.8 CPR Release
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 26 Affinity® Three Birthing Bed and Affinity® Four Birthing Bed
Service Manual (MAN272 REV 4)
4.8 CPR Release
Tools required: Adjustable wrench
Adjustment
1. Set the brake/steer pedal to the brake position.
2. Ensure that the bed is out of the Trend-Like position.
3. Using the hilow function, place the bed in a mid-height position.
4. Using the head function, raise the head section to its highest position.
5. Ensure that the siderails are in the up position.
Unplug the unit from its power source. Failure to do so could result in
personal injury or equipment damage.
6. Unplug the bed from its power source, and engage the lockout control.
7. Remove the top motor cover (refer to procedure 4.1).
8. Ensure that the CPR cables (A) are routed inside the head section
weldment (B) (see figure 4-12 on page 4-26).
Figure 4-12. CPR Release
