4.7 Foot Limit Switch
Chapter 4: Removal, Replacement, and Adjustment Procedures
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 4 - 25
Service Manual (MAN272 REV 4)
4
j. Check the gap (A) between the foot section left-hand lift arm (B) and
the hilow left-hand lift arm (C) at the low position. Verify that the
distance (A) is exactly ¼" (6.4 mm).
k. Repeat step a through step j until the correct foot level position is
obtained.
2. Do the “Function Checks” on page 2-4.
