4.38 Permanant IV Pole—P3732A
Chapter 4: Removal, Replacement, and Adjustment Procedures
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 4 - 95
Service Manual (MAN272 REV 4)
4
4.38 Permanant IV Pole—P3732A
Tools required: T25 Torx® screwdriver
Removal
1. Set the brakes.
WARNING:
Failure to unplug the bed could cause injury.
2. Unplug the bed.
3. Remove the two screws (A) from the IV pole (B) (see figure 4-47 on
page 4-95).
4. Remove the IV pole (B) from the bed (C).
Figure 4-47. IV Pole
Replacement
Do the removal procedure in reverse order.
