Hill-Rom Affinity Three - Headboard-Wood Style

Headboard—Wood Style
Chapter 5: Parts List
Page 5 - 58 Affinity® Three Birthing Bed and Affinity® Four Birthing Bed
Service Manual (MAN272 REV 4)
Headboard—Wood Style
Figure 5-22. Headboard
Table 5-22. Headboard
Item Number Part Number Quantity Description
1 43878 2 Screw, button hd Torx®
2 37664 2 Clip, IV
3 31773 10 Screw
4 40995 1 Handle weldment, headboard
165456 1 Weldment, headboard, w/o handles
5 42600 2 Plug
6 42588 2 Grip, handle, foam
7 41114
or
112769
or
112770
1 Headboard, wood
or
Headboard, wood—Liberty Hill™
or
Headboard, wood—Freedom Hill™
No shown 169548 1 Label, Do not push, wood headboards
w/o handles
