Hill-Rom Affinity Three - Line Manager

Line Manager
Chapter 5: Parts List
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 5 - 111
Service Manual (MAN272 REV 4)
5
Line Manager
Figure 5-41. Line Manager
Table 5-41. Line Manager
Item Number Part Number
Quantity
a
a. Quantities shown are for each line manager.
Description
1 9001624H 2 Bolt
2 831 2 Nut
3 127357 2 Washer
4 16527001 1 Weldment, rh
16527002 1 Weldment, lh
5 146287 1 Flex arm
6 152908 1 Nut
