Hill-Rom Affinity Three - Initial Actions; Quick Reference Problem;Solution Matrix

Initial Actions
Chapter 2: Troubleshooting Procedures
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 2 - 3
Service Manual (MAN272 REV 4)
2
WARNING:
Unplug the bed from its power source and disconnect the battery
back-up before checking ohms/resistance measurements. Failure to
disconnect line voltage to the bed can damage the VOM and cause
equipment damage or personal injury.
Initial Actions
To gather information from operators concerning problems with the bed, use
Initial Actions. Note symptoms or other information concerning the problem
that the operator describes. This information helps identify the probable cause.
1. Someone who can explain the problem is available.
Yes No
Go to “Function Checks” on page 2-4.
2. Ask that person to demonstrate or explain the problem. The problem can be
duplicated.
Yes No
Go to “Function Checks” on page 2-4.
3. The problem is a result of improper operator action.
Yes No
Go to “Function Checks” on page 2-4.
4. Instruct the operator to refer to the procedures in the Affinity® Three
Birthing Bed and Affinity® Four Birthing Bed User Manual (USR025). Do
the “Function Checks” on page 2-4.
Quick Reference Problem/Solution Matrix
If a problem with the bed system is readily identified, use table 2-1 on page 2-4
to quickly go to the applicable troubleshooting procedure. If the problem is not
readily identified, go to “Function Checks” on page 2-4.
