4.16 Foot Section (Lift Off)
Chapter 4: Removal, Replacement, and Adjustment Procedures
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 4 - 41
Service Manual (MAN272 REV 4)
4
4.16 Foot Section (Lift Off)
Tools required: None
Removal
1. Pivot the foot mattress side panels (A) up (see figure 4-21 on page 4-42).
2. Grasp the mattress handles (B) or (G) located on both sides of the mattress.
3. Pull straight up and then toward yourself.
4. Stand the foot section up on the pull handle (C) base or on the perineal
stand.
Replacement
WARNING:
Failure to properly mount the foot section to the yoke latches could
result in equipment damage or personal injury.
1. Grasp the mattress handles (B) or (G) located on both sides of the mattress.
2. Align the foot section slides (D) with their receptacles (F) on the bed.
3. Lower the foot section (E) onto the bed.
4. Tug upward on the pull handle (C) to verify that the foot section is securely
mounted to the bed.
