4.33 Stow and Go® Foot Section Wire Form
Chapter 4: Removal, Replacement, and Adjustment Procedures
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 4 - 83
Service Manual (MAN272 REV 4)
4
4.33 Stow and Go® Foot Section Wire Form
Tools required:
Removal
1. Set the brakes.
2. Raise the bed to the full up position.
3. Raise the foot section to the full up position.
WARNING:
Failure to unplug the bed can cause personal injury or equipment
damage.
4. Unplug the bed from its power source.
5. Remove the placenta basin (A) from the foot section (B) (see figure 4-42
on page 4-84).
6. Remove the foot section (B).
7. Remove the two screws (C) that secure the wire form (D) to the foot
section weldment (E).
8. Remove the two nuts (F) from the bolts (G).
9. Support the weight of the wire form with one hand.
10. Remove one bolt (G).
11. Remove the other bolt (G).
12. Remove the wire form (D) from the bed.
