4.6 Foot Drive Motor Assembly
Chapter 4: Removal, Replacement, and Adjustment Procedures
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 4 - 19
Service Manual (MAN272 REV 4)
4
4.6 Foot Drive Motor Assembly
Tools required: T25 Torx®
1
head bit Ratchet
Needle nose pliers
Bed stands, or (4) pieces of 2" x 4" x 32" lumber
Removal
1. Set the brake/steer pedal to the brake position.
2. Using the hilow function, raise the bed to the high position.
3. Using the head function, raise the head section to the high position.
SHOCK HAZARD:
Unplug the unit from its power source. Failure to do so could result in
personal injury or equipment damage.
4. Unplug the bed from its power source, and engage the lockout control.
5. Remove the top motor cover (refer to procedure 4.1).
6. Remove the bottom motor cover (refer to procedure 4.2).
7. Perform step 7 through step 10 in “Hilow Drive Motor Assembly” on
page 4-7.
WARNING:
You must use the 2" x 4" pieces of lumber to support the bed. The bed
will fall during this procedure if not supported. Failure to support the bed
could result in personal injury or equipment damage.
CAUTION:
Ensure that the night light is not damaged when the bed is being
lowered. Failure to do so could result in equipment damage.
WARNING:
You must use the 2" x 4" pieces of lumber to support the foot yoke. The
foot yoke will fall during this procedure if not supported. Failure to do so
could result in personal injury or equipment damage.
8. Place the remaining 2" x 4" pieces of lumber below the foot yoke.
1. Torx® is a registered trademark of Textron, Inc.
