4.19 Battery Assembly
Chapter 4: Removal, Replacement, and Adjustment Procedures
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 4 - 47
Service Manual (MAN272 REV 4)
4
4.19 Battery Assembly
Tools required: T25 Torx®
1
head bit Ratchet
VOM Small screwdriver
Adhere to all electrical safety precautions when servicing the bed's
electrical system. Failure to do so could result in personal injury or
equipment damage.
Batteries
Removal
1. Set the brake/steer pedal to the brake position.
2. Ensure that the bed is out of the Trend-Like position.
3. Using the head function, raise the head section to the high position.
4. Using the hilow function, raise the bed to the high position.
Unplug the unit from its power source. Failure to do so could result in
personal injury or equipment damage.
5. Unplug the bed from its power source, and engage the lockout control.
6. Remove the top motor cover (refer to procedure 4.1).
Do not cut or remove the cable ties that secure the battery leads to the
electronics pan. This ensures the proper connection of the batteries
during the replacement procedure. Possible equipment damage could
occur if the cable ties are removed.
7. Unplug the battery cable assembly (A) from logic control P.C. board
connector P5 (see figure 4-24 on page 4-48).
8. Unplug the battery cable assemblies (A and B) from the four connection
points (C) on the two batteries (D).
1. Torx® is a registered trademark of Textron, Inc.
