4.27 Siderail Assembly
Chapter 4: Removal, Replacement, and Adjustment Procedures
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 4 - 67
Service Manual (MAN272 REV 4)
4
4.27 Siderail Assembly
Tools required: Small screwdriver Ratchet
Needle nose pliers 7/16" socket
WARNING:
Adhere to all electrical safety precautions when servicing the bed’s
electrical system. Failure to do so could result in personal injury or
equipment damage.
Removal
1. Set the brake/steer pedal to the brake position.
2. Ensure that the bed is out of the Trend-Like position.
3. Using the head function, raise the head section to the high position.
SHOCK HAZARD:
Unplug the unit from its power source. Failure to do so could result in
personal injury or equipment damage.
4. Unplug the bed from its power source.
5. Disconnect the siderail cable (A) from the cable (B) to the logic control
P.C. board (see figure 4-36 on page 4-68).
6. Disconnect the ground strap (H).
CAUTION:
Support the siderail during the removal procedure. Failure to do so
could result in equipment damage.
7. Using the needle nose pliers or a small screwdriver, remove the four
e-rings (C) that secure the siderail assembly (D) to the head section.
8. Using a ratchet and 7/16" socket, remove the two nuts (E) and bolts (G)
that secure the siderail mounting bracket (F) to the head section.
