4.8 CPR Release
Chapter 4: Removal, Replacement, and Adjustment Procedures
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 4 - 27
Service Manual (MAN272 REV 4)
4
9. Ensure that the CPR cables (A) are secured loosely with the cable tie (C)
located on the head drive motor assembly.
The cable tie should be snug enough to secure the cable, but not tight enough to
pinch the cable sheath.
10. Using a wrench, adjust the CPR cable tensioning nuts (D) until the CPR
release works properly on both sides of the bed.
11. Do the “Function Checks” on page 2-4.
