4.17 Foot Section (Slide Off)
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 44 Affinity® Three Birthing Bed and Affinity® Four Birthing Bed
Service Manual (MAN272 REV 4)
Replacement
Failure to properly mount the foot section to the yoke slide brackets
could result in equipment damage or personal injury.
1. Grasp the mattress handles (B) located on both sides of the mattress
(see figure 4-21 on page 4-42).
2. Align the foot section channel slides (F) with the mounting brackets (G) on
the bed(see figure 4-22 on page 4-43).
3. Slide the foot section onto the bed.
4. Ensure that the foot section latch mechanism (E) locks into the channel
slide (F).
5. Tug out on the pull handle (C) to verify that the foot section is securely
mounted to the bed.
