Base Module—P/N 63951S (Sheet 1 of 2) (P3700A)
Chapter 5: Parts List
Affinity® Three Birthing Bed and Affinity® Four Birthing Bed Page 5 - 11
Service Manual (MAN272 REV 4)
5
Table 5-3. Base Module—P/N 63951S (Sheet 1 of 2) (P3700A)
Item Number Part Number Quantity Description
1 43878 16
Screw, button hd Torx®
a
a. Torx® is a registered trademark of Textron, Inc.
2 41002 4 Spacer, rocker arm,
3 41269 4 Leg cover
4 32425 2 Set screw, hex socket hd
5 43030 4 Spring washer, caster
6 32572 4 Screw
7 18890 4 Truarc ring
8 41001PL 2 Groove pin, rocker arm
9 4258358 2 Brake/steer disc—green
10 41237 2 Pad, right
11 4258360 2 Brake/steer disc—orange
12 41238 2 Pad, left
13 43940 1 Brake pedal assembly, lh
14 9034002 2 Bearing, DU flanged
15 44017PL 2 Bracket, brake rod support
16 439460148 1 End cap, cross tube, lh
17 46260 4 Screw, button hd Torx®
18 32909 8 Locknut
19 90055-10 4 Screw, pan hd truss
20 43953 2 Cam pivot
21 755 4 Locknut
22 43955PL 1 Brake strip
23 757 2 Pin, connector
24 44352 4 Hairpin
25 34715 2 Rocker arm assembly
26 43957 1 Plate, detent housing
27 44350 2 Clevis pin
28 44023 1 Detent mechanism assembly
29 6722548 2 Base frame weldment
